Polypropylene high strength FDY production line
Polypropylene high strength FDY production line
Polypropylene high strength FDY production line
  • Polypropylene high strength FDY production line:The spun polypropylene screw extruder, equipped with large area of the melt filter and with efficient static mixer and spinning beam. bottom round-shaped or tops rectangle-shaped spinning components, lateral blow and oiling system, heating roll and switch automatic winding machine.
Product Description
  •



    The  spun  polypropylene screw extruder, equipped with large  area  of  the  melt  filter  and    with  efficient  static  mixer  and  spinning  beam. bottom  round-shaped  or  tops  rectangle-shaped  spinning  components,  lateral  blow  and  oiling  system,  heating  roll  and  switch  automatic  winding  machine.


     The main technical parameters of polypropylene high strength FDY production line

    Polypropylene high-strength FDY production line machine parts: 1,2,4

    Polypropylene high strength FDY production line spinning pitch: 1200 ~ 2000mm

    Polypropylene high-strength FDY production line per spinning head number: 2,4,6,8

    Polypropylene high strength FDY production line Finished silk fineness: 180D ~ 2100D

    Polypropylene high strength FDY production line screw diameter: Φ30mm ~ Φ120mm

    Polypropylene high strength FDY production line Draft roller size: Φ190 × 330mm or Φ180 × 280mm

    Propylene polypropylene high strength FDY production line winding speed: 1500 ~ 3000m / min

    Polypropylene high strength FDY production line for winding machine: A435 or A635 or A835



    Polypropylene high-strength FDY production line main features:

    l lengthened screw extruder, AC frequency control

    l The new spinning machine and mixed homogeneous melt line

    l with large plate spinneret, round or rectangular top self-sealing components

    l The use of accurate measurement of the planetary gear pump and put the bit extension fast drive rod

    l with uniform and stable side of the blowing device, large flow sprinkler oil system

    l use of environmentally friendly energy-saving medium electric heating system, import smart instrument control

    l using 3 ~ 5 drafting roller drafting and heat setting, the new final network device

    l using domestic automatic switch winding machine

    l installation of the edge of the switch can be used to produce renewable raw materials Pu thick filament

    l high strength wire strength warranty at 7 g / d or more


    Polypropylene high strength FDY production line, the  spun  polypropylene    screw  extruder,  equipped  with  large  area  of  the  melt  filter  and    with  efficient  static  mixer  and  spinning  beam.  bottom  round-shaped  or  tops  rectangle-shaped  spinning  components,  lateral  blow  and  oiling  system,  heating  roll  and  switch  automatic  winding  machine.
